EPSON SureColor V1070 Desktop UV Flatbed Printer

• Low initial investment — less than half the cost of comparable desktop flatbed UV printers
• High-quality output — delivers vivid colors, low graininess and smooth gradations
• Compact and unique design — breakthrough space-saving design easily fits into your workflow
• User-friendly — simple operation and easy maintenance
• UltraChrome UV Ink — for precise, versatile and durable printing
• Varnish Ink — choose between Gloss and Matte Varnish for finishes, textures and other embellishments
• White Ink — for high White opacity on clear or dark substrates
• Media versatility — prints directly on acrylic, wood and other materials across a wide range of promotional items, such as keychains, golf balls and pens
• World-class service and support — includes limited warranty; extended service plans available

• RoHS compliant
• End of life options available
• Epson America, Inc. is a SmartWay® Transport Partner

Print

Printing Technology MicroPiezo® printhead featuring variablesized droplet control

Ink UltraChrome UV Ink

Ink Configuration C, M, Y, K, Wh, Vr

Nozzle Configuration 1,440 nozzles

Maximum Resolution 1440 x 1440 dpi

Ink

Ink Pack Fill Volume3 140 mL each color x 8 colors total; 140 mL cleaning liquid pack

Included Ink in the Box 140 mL each color x 8 ink packs total (CMYK + 2 Wh + 2 Vr)

Printer is designed for use with Epson ink packs only,  not third-party ink systems.

Printer Interfaces

USB 3.0

Network 100Base-TX / 1000Base-T / IEEE 802.11 b/g/n/az/ac / JBMIA_Interfaces

Available Software

Web Installer/Firmware Updater/Epson Manual Launcher

Epson Edge® Print Pro

Epson Edge Dashboard

Epson Cloud Solution PORT

All software and documentation available via Web download.

Media Handling

Maximum Media Size 8.3" x 11.7" (210 mm x 297 mm)

Maximum Media Thickness 2.7" (70 mm)

Maximum Media Weight (Including Jig) 6.5 lb (3 kg)

Maximum Printing Area 8.3" x 11.7" (212 mm × 299 mm)

General

Printer Control 4.3" LCD touch panel

Weight and Dimensions (W x D x H) Dimensions: 28" x 28" x 17" (699 mm x 699 mm x 426 mm) Weight: 131 lb (59 kg)

Acoustic Noise Level Approximately 52 dbA

Temperature Operating: 59 ˚F to 86 ˚F (15 ˚C to 30 ˚C)

Relative Humidity Operating: 20% – 80% Storage: 5% – 85%

Electrical Requirements Voltage: AC 100 V – 120 V Frequency: 50 Hz – 60 Hz

Power Consumption Operating: Approx. 170 W Standby: 80 W Sleep Mode: 2.6 W Power Off: 0.1 W

What's Included

SureColor V1070 Printer, AC Power Cable, Epson Edge Print PRO Software, Set of Eight 140 mL Ink Packs, Ink Charging Tool, Tray Attachment, Cleaning Ink Supply Unit, Jig Disposal Bags (x 2),  Pair of Gloves, Wiper Unit, Air Filter (2 sets), Scraper, Hex Key, Warranty/Registration Card, Printer Manual
