TITAN 16” x 20” Auto Open Dual Station Heat Press

TITAN 16” x 20” Auto Open Dual Station Heat Press

MicroTec USA

SKU:

$1,990.00 USD
$2,399.00 USD $1,990.00 USD
Sale Sold out

Payment & Security

Payment Methods Accepted

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Shipping, Crating, and Packaging Fees

Additional Shipping & Crating Fees

Lawson made equipment comes with a Shipping and Crating Charge that is not included in the price shown and will not be reflected in your order's total. We will contact you after order completion with a final cost.

Download Product's PDF Brochure

Financing Options

Need to finance the TITAN 16” x 20” Auto Open Dual Station Heat Press? No problem! Visit our Financing Page for more details.

Got a question about this product?

Questions & Answers

How does the dual-station sliding system increase productivity?

The dual-station design allows an operator to thread, center, and align a second shirt on one platen while the press completes a heat cycle on the opposite station, eliminating machine downtime between garments.

Does the TITAN 16" x 20" Auto Open Dual Station Press require an air compressor?

No, this model utilizes manual clamping with an electromagnetic auto-open release, so no external air compressor is required.

What are the advantages of the upgraded 20%+ thicker heating platen?

The extra thickness allows the heating platen to hold heat more effectively during continuous high-speed production runs, preventing temperature drops and cold spots across the 16" X 20" area.

Can I save preset parameters for different transfer types?

Yes. The digital touchscreen interface allows you to program and save up to 3 custom job memory presets for fast switching between DTF transfers, HTV vinyl, screen print transfers, and sublimation.

Where does the TITAN press ship from and how is technical service supported?

Orders ship directly from the primary distribution hub in California, supported by regional technical service and customer support teams across St. Louis, Atlanta, Phoenix, Orlando, and Des Moines.

View full details
Jump to: Description The LWG Difference Features Specifications Table Comparison Table

Description

Maximize shop productivity, eliminate downtime between cycles, and double your production capacity with the TITAN 16” x 20” Auto Open Dual Station Heat Press. Built specifically for high-volume custom garment decorators, contract print shops, and DTF production hubs, this heavy-duty commercial press combines dual-station workflow efficiency with reliable electromagnetic auto-release technology.

Featuring dual sliding lower platens, the TITAN allows operators to load, position, and thread a garment on one station while the opposite station is actively pressing under heat. At its core is an upgraded heating element over 20% thicker than standard models, delivering exceptional heat retention, rapid thermal recovery, and edge-to-edge consistency. Equipped with a double-bar leverage handle and an advanced digital touchscreen controller with three job presets, switching between DTF transfers, HTV vinyl, screen print transfers, and dye sublimation takes only seconds.

Maximize shop productivity, eliminate downtime between cycles, and double your production capacity with the TITAN 16” x 20” Auto Open Dual Station Heat Press. Built specifically for high-volume custom garment decorators, contract print shops, and DTF production hubs, this heavy-duty commercial press combines dual-station workflow efficiency with reliable electromagnetic auto-release technology.

Featuring dual sliding lower platens, the TITAN allows operators to load, position, and thread a garment on one station while the opposite station is actively pressing under heat. At its core is an upgraded heating element over 20% thicker than standard models, delivering exceptional heat retention, rapid thermal recovery, and edge-to-edge consistency. Equipped with a double-bar leverage handle and an advanced digital touchscreen controller with three job presets, switching between DTF transfers, HTV vinyl, screen print transfers, and dye sublimation takes only seconds.

The LWG Difference

When you source commercial heat presses and decorating machinery from Lawson Workhorse Group (LWG), you get far more than hardware—you gain an industry-leading technical partner backed by decades of screen printing and digital decorating expertise. Your investment is supported by our primary distribution hub in California alongside satellite technical service centers in St. Louis, Atlanta, Phoenix, Orlando, and Des Moines. From setup guidance to long-term replacement parts, LWG ensures your shop maintains maximum uptime and operational efficiency.

When you source commercial heat presses and decorating machinery from Lawson Workhorse Group (LWG), you get far more than hardware—you gain an industry-leading technical partner backed by decades of screen printing and digital decorating expertise. Your investment is supported by our primary distribution hub in California alongside satellite technical service centers in St. Louis, Atlanta, Phoenix, Orlando, and Des Moines. From setup guidance to long-term replacement parts, LWG ensures your shop maintains maximum uptime and operational efficiency.

Features

Dual Sliding Lower Platens: Maximizes hourly output by allowing seamless loading and alignment on one platen while the other is pressing.

Over 20% Thicker Heating Element: Delivers superior thermal core retention, rapid recovery, and uniform heating across the full 16" X 20" surface.

Electromagnetic Auto-Open System: Pops open automatically when the timer cycle completes to protect garments from over-curing or scorching.

Touchscreen Control System: Easily program time and temperature settings, monitor real-time pressure, and save up to 3 custom job presets.

Double-Bar Lever System: Ergonomic pull-down handle applies smooth, uniform downward pressure to ensure crisp transfer adhesion with reduced operator strain.

Dual Sliding Lower Platens: Maximizes hourly output by allowing seamless loading and alignment on one platen while the other is pressing.

Over 20% Thicker Heating Element: Delivers superior thermal core retention, rapid recovery, and uniform heating across the full 16" X 20" surface.

Electromagnetic Auto-Open System: Pops open automatically when the timer cycle completes to protect garments from over-curing or scorching.

Touchscreen Control System: Easily program time and temperature settings, monitor real-time pressure, and save up to 3 custom job presets.

Double-Bar Lever System: Ergonomic pull-down handle applies smooth, uniform downward pressure to ensure crisp transfer adhesion with reduced operator strain.

Specifications Table

Model Name TITAN 16" x 20" Auto Open Dual Station Heat Press
Workstation Count 2
Platen Size 15.7" x 19.7"
Production Capacity Up To 150 Units/hour*
Temperature Range 32-446°F
Time Range 0-999
Shipping Size 44.5" x 35.8" x 32.3"
Air Requirements (CFM) 0.0 CFM
Power Consumption 1700W
Voltage 120V
Amps 14.2A
Machine Dimensions 59" x 41" x 31"
Method of Operation Double Station & Auto Open
Machine Line Titan
Shipping Weight 363.7 lb
Net Weight 247 lb
Color Silver

Comparison Table

FEATURE / SPEC TITAN 16" X 20" AUTO OPEN DUAL STATION vector 16 x 20 auto open slide out heat press
Platen System Dual Sliding Lower Workstations Single Slide-Out Drawer Platen
Production Workflow Continuous Dual Prep (Zero Machine Idle) Standard Single-Garment Prep
Platen Thickness Upgraded 20%+ Thicker Heating Platen Standard Commercial Platen
Release Mechanism Electromagnetic Auto-Open Electromagnetic Auto-Open
Pressure Control Real-Time Touchscreen Pressure Sensor Manual Pressure Adjustment Knob
Ideal Production Volume High-Volume Continuous Commercial Runs Medium-to-High Output Production
Regional Support Network LWG Support Hubs (St. Louis, GA, etc.) LWG Support Hubs (St. Louis, GA, etc.)
